Vacuum Excavator

  • Fuel Type: Diesel
  • Power: 31 hp (23.1 kW)
  • Capacity: 250 gal spoil, two 50 gal water saddle tanks
  • Blower Output: 575 CFM blower output
  • Max. Vacuum: 15 in’Hg
VX30-250
VX30-250

Features

The VX30-250 offers a low-cost, highly portable system for potholing, valve box clean out and a range of non-destructive digging tasks in industries including water, gas and fibre installation.

Key Features

  • THE VX30-250 vacuum excavator offers municipalities and contractors a low-cost, portable system for potholing and vacuum applications such as hydro excavation and liquid vacuum recovery.
  • The VX30-250 features convenient curbside controls for domestic and international use.
  • Saves you cleanup time and makes it easier to remove difficult debris as it delivers a high-pressure water spray to the tank interior while simultaneously dumping material.
  • Integrated silencing system for quieter operation by dampening sound before it’s released into the atmosphere using an external engine compartment baffle system.
  • Reduces the risk of material entering the blower – in turn, adding greater longevity to your system.

Weights and Dimensions

  • Trailer GVW: 9850 lb / 4467.9 kg
  • Trailer Empty Weight: 4519 lb / 2050 kg
  • Trailer Axles: Two 6000 lb tandem with electric brakes / Two 2721 kg tandem with electric brakes
  • Trailer Unit Length: 152 inches / 386 cm
  • Trailer Unit Width: 87 inches / 221 cm
  • Trailer Unit Height: 83 inches / 211 cm

General

  • Spoil Tank Capacity: 250 gal / 946.4 L
  • Engine: 31 hp Yanmar diesel / 23.1 kW
  • Blower: 575 cfm Lobe type with dual-splash oil lubrication / 16.3 m3/min
  • Maximum Vacuum: 15” Hg / 381 mm Hg
  • Water Tank Capacity: Two 50 gal saddle tanks / Two 189 L saddle tanks
  • Water Pump: 5.6 gpm @ 3000 psi / 21.2 L/min @ 206.8 bar
  • Filtration: 3-stage with cyclone separator & 2-micron poly filter

Operational

  • Controls: Australian kerb-side electric start and throttle, full spoil tank override, water pump clutch
  • Gauges: Australian kerb-side fuel level, vacuum, water pressure, hour meter
  • Enclosure: Lockable, sound-dampening
  • Door Type: Full open, manual
  • Fuel Tank: 20 gal / 76 L
  • Full spoil tank shutoff: Electronic float, ball float back up
  • Spoil Tank Lift: Dual hydraulic cylinders
  • Vacuum Hose: 18’ of 3” – two 9’ sections / 5.5m of 7.6m – two 2.7m sections
  • Low Water Shutoff: Electronic
